How Thick Should Corten Steel Be for a Retaining Wall?
Date:2025.10.31
Share to:
Corten retaining walls, combining industrial aesthetics with structural strength, have long been a popular choice in modern garden design. Yet many homeowners and designers encounter a critical question when planning: “How thick should the steel be to ensure both safety and durability?”
The answer is clear: thickness is not merely an aesthetic choice but a core factor affecting structural safety.Only with the correct thickness can a metal retaining wall effectively withstand soil pressure, prevent corrosion damage, and truly achieve decades of service life.
For users seeking long-term value, a properly sized weathering steel retaining wall not only requires less maintenance than concrete or wood but also develops a unique rust patina over time. We offer comprehensive solutions ranging from standard sizes to custom designs tailored to project requirements.
A corten retaining wall is fundamentally a structural landscape element with the core function of “soil retention”: it supports soil weight, creates elevation changes in gardens (such as elevated decks or planting beds), and can even bear the load of small platforms. Beyond its practicality, its aesthetic value is equally striking: Initially installed as a light gray, it naturally weathers over 2-6 months to develop a warm orange-brown rust patina, adding a unique blend of vintage and modern charm to any landscape.
2. Don't Confuse It With Garden Edging
Many confuse metal garden retaining walls with standard garden edging, but their functions and steel requirements are entirely different:
Edging: Made from 1-2mm thick steel, used solely to separate lawns and flower beds. It bears no soil pressure and is not technically a steel retaining wall panel.
Weathering steel retaining wall: Requires significantly thicker steel to withstand the “lateral pressure” (horizontal thrust) exerted by soil, preventing wall bending or collapse.
Selecting Thickness Based on Retaining Wall Height
1. Decorative Edging (Below 300mm/12 inches)
Applicable Scenarios: Low flower bed borders, small greenery areas serving purely aesthetic separation with minimal soil pressure;
Steel Thickness: 1.5mm -2.0mm (16-14 gauge);
Note: This does not constitute a true metal retaining wall. Suitable only for light decorative applications; cannot be used for soil retention or terrain elevation.
2. Small Cor-Ten Steel Retaining Walls (300mm-600mm/1-2 feet)
Applications: Standard garden planting beds, low-rise elevated lawns with moderate soil pressure;
Steel thickness: Minimum 3.0mm (11 gauge) Cor-Ten A steel;
Our recommended solution: 3mm thick steel retaining wall panels with bolted assembly design, complete hardware kit for DIY installation — stabilized by widened bases without additional ground anchoring, easy for beginners.
3. Medium Structural Retaining Walls (600mm-1200mm / 2-4 ft)
Suitable Scenarios: Raised decks, medium soil embankments requiring high soil pressure resistance;
Steel Thickness: Industry standard 4.0mm-5.0mm (9-7 gauge);
Essential Pairing: Thickness alone is insufficient; must be paired with a support/anchoring system—such as deeply embedding internal columns underground and welding or bolting Corten retaining wall panels to these columns—to effectively distribute lateral pressure and prevent wall bulging or collapse.
Suitable scenarios: Major terrain modifications, high-gradient areas in commercial landscapes with extreme soil pressure;
Steel Thickness: Corten steel 6.0mm and above;
Critical Note: Projects of this scale require on-site calculations by a licensed structural engineer (considering soil type and load conditions) to customize steel retaining wall panel dimensions and jointing methods — our team provides engineering support to ensure safe, compliant solutions.
How Does Thickness Determine the Lifespan of Corten Steel Retaining Walls?
1. The Challenge of Dual-Sided Corrosion
Weathering steel retaining walls face a unique corrosion dilemma: the outer surface endures wind and rain, while the inner side remains in constant contact with moist soil. The inner steel remains perpetually damp, unable to form a stable protective rust layer through “wet-dry cycles” like the exterior. Instead, it undergoes slow, continuous corrosion.
2. Thickness Acts as a “Sacrificial Layer”
For corten retaining walls, the additional steel thickness serves as a “corrosion allowance”: thicker steel prolongs the time required for corrosion to penetrate the inner surface, thereby maintaining the wall's structural integrity for longer.
For example, a medium-sized retaining wall with 4mm-5mm thickness can withstand decades of wear even with minor annual corrosion on the inner side, ultimately achieving a service life exceeding 40-50 years. Conversely, a medium wall using 3mm steel may develop safety hazards within a decade due to internal corrosion.
3. Drainage: The “Lifespan Booster” Essential Regardless of Thickness
Regardless of the thickness of your metal garden retaining wall, drainage is crucial for extending its lifespan:
A layer of crushed stone or gravel must be laid behind the wall, with drainage holes reserved in the wall foundation or drainage pipes installed.
Function: Releases hydrostatic pressure in the soil, allowing the inner steel to occasionally dry out and significantly slowing corrosion rates. Poor drainage will accelerate corrosion even in thick steel.
Other Key Considerations: Aesthetics, Cost, and Fabrication
Aesthetics: Thickness Affects Wall Flatness
Thick steel (4mm+): Offers greater rigidity, resists deformation during installation and backfilling, maintains straight and level walls, and prevents the “barrel effect” (wall unevenness). Particularly suited for modern minimalist gardens.
Thin steel (1.5mm–2mm): Prone to bending, may result in uneven walls after installation. Suitable only for low-demand decorative applications; not recommended for metal retaining walls.
Cost: An initial investment for long-term peace of mind
Thicker steel incurs higher upfront procurement and fabrication costs but proves more economical over time: For instance, a 4mm metal retaining wall lasts 40 years, while a 3mm wall may require replacement after 20 years. The combined cost of two replacements (materials + labor) exceeds the single investment in thicker steel.
More critically, replacing retaining walls disrupts existing landscape designs, incurring additional time and financial costs.
Steel plates 4mm and thicker allow for superior structural welding: Joints achieve sufficient strength to withstand soil pressure, ensuring durable connections between steel retaining wall panels.
Customization advantage: Thicker steel offers greater malleability, allowing us to fabricate straight, curved, or even angled Corten retaining wall panels to accommodate irregular garden layouts.
Frequently Asked Questions for Corten Steel Retaining Wall Thickness
1. Can 3mm Corten Steel Be Used For A 800mm-High Retaining Wall?
Not recommended. At 800mm, the wall falls within the medium-sized structural category (600mm-1200mm range). 3mm steel lacks sufficient strength and corrosion allowance, making it prone to failure under long-term soil pressure. Not recommended. A 800mm wall falls within the medium-sized structural retaining wall category (600mm-1200mm range). 3mm steel lacks sufficient strength and corrosion allowance, making it prone to deformation under soil pressure or premature failure due to internal corrosion over time. A minimum 4mm steel thickness is required, supplemented by a support system.
2. Should Corten Steel Retaining Walls Have a Top Edge Fold?
Recommended. Without a top fold, edges of thin steel (3mm or less) remain sharp and lack rigidity, risking cuts or deformation. Even with 4mm+ steel, a top fold reduces edge corrosion, enhancing durability and aesthetics for weathering steel retaining walls.
3. How Long Does It Take For The Rust Patina To Form On a Corten Steel Retaining Wall?
Typically 2-6 months, depending on local climate: faster in rainy, humid regions; slower in dry areas. The patina transitions from an initial light gray to a warm orange-brown hue, forming naturally without painting as a protective layer.
4. Is Corten Steel Retaining Wall Better Than Concrete Walls?
Yes, based on the overall value. Corten retaining walls are lighter, install faster (modular panels require no on-site pouring), and develop a unique aesthetic appeal over time. Concrete walls are heavy, have longer construction cycles, and offer less visual interest. Additionally, Corten steel is 100% recyclable, aligning better with environmental principles.
5. Can I Install Corten Steel Retaining Walls Myself?
Small walls (300mm-600mm) with 3mm thickness can be DIY-installed. Our steel retaining wall panels come with detailed installation instructions and complete hardware kits. However, for medium (600mm+) or large walls, professional installation is recommended—we offer on-site installation services to ensure structural safety.
Choose the Right Thickness to Make Your Corten Retaining Wall a Lasting Landscape Asset
A corten retaining wall is a long-term investment, and thickness is key to determining its value. For most home gardens, a 3mm thin wall or a 4mm-5mm medium wall suffices; larger projects require professional calculations to select steel 6mm or thicker.
Remember: Safety and durability always come first. Only then can a weathering steel retaining wall truly become a practical and beautiful garden highlight, enhancing your outdoor space for decades.
Looking to customize the perfect corten retaining wall for your garden? Explore our product lineup: 3mm modular panels (DIY-friendly), 4mm-5mm medium-duty structural kits (with support systems), and customizable curved/corner steel retaining wall panels.
Simply provide your garden dimensions and requirements, and we'll offer complimentary thickness recommendations and quotes. All products ship flat-packed (saving shipping space) nationwide. We also provide engineering calculations and on-site installation services for a completely hassle-free experience!
